Multi-functional LED dim controller is dedicated to control single color led changes, LED lighting's brightness and synchronic color changing effect.
Note: If used together with amplifier, each can control twice the quantity of LED lights by every adding one more,
which can achieve the unlimited output power repeating.
Specification
- Voltage: DC12V/ DC24V
- Function Keys: 3 keys( On /off , Brightness up, Brightness down)
- Changeable Brightness: 64 levels
- Color depth：256 levels
- Output: 1 Channel
- Related Current: < 8A each channel
- Output Power: 12V < 96W, 24V < 192W
- Size: L110*W56*H34mm
- Pakage Size: L122*W85*H42 mm
- N / W: 100g
- G / W: 130g
